TC2030-CTX · 6-Pin Cable for ARM Cortex
€50.00
- From 1 pcs: €50.00 / pc
- From 20 pcs: €46.00 / pc
- From 30 pcs: €45.00 / pc
Available, delivery time: 1-3 days
More than 5 in stock
Product information "TC2030-CTX · 6-Pin Cable for ARM Cortex"
Short description
6-pin TC2030 Plug-of-Nails™ cable, legged, for ARM Cortex targets. 10-pin ribbon connector in FTSH-105 format (Cortex Debug standard, e.g. Keil ULINK2).
Important note (Atmel-ICE)
Atmel-ICE has its header pin numbers reversed (standard pin 1 = Atmel-ICE pin 10). Connecting this cable unmodified to an Atmel-ICE can cause a short circuit and component damage — either cut off the ribbon connector's locating lug and plug it in reversed, or order the LEMTA variant directly.
Technical data
- Target connector: 6-pin Plug-of-Nails™, legged
- Host connector: 10-pin ribbon (FTSH-105 compatible)
Compatible debuggers/platforms
Cortex-10/MIPI-10 generic (SWD) · Cypress Miniprog 3 & 4 · ARM Keil ULINK2 · Atmel ICE (LEMTA option or manual reversal only)
Included
Cable only. Debugger and demo PCB shown in product photos are for illustration, not included.
Variants
TC2030-CTX-NL — same function, no legs.
| Bauform: | Legged |
|---|
Manufacturer's datasheet (PDF, copy hosted by us)
Accessories
Connects a TC2030-IDC or TC2030-IDC-NL cable to a 20-pin ARM SWD target. Also works when the target board carries a 6-pin 0.1″ IDC header instead of the classic 20-pin header.
- from 1 pcs €38.00
- from 20 pcs €34.96
- from 30 pcs €34.20
Protective cap for the 6-pin TC2030 cable family (Plug-of-Nails™). Protects spring contacts, steel guide pins and — where present — retention tabs during storage and transport.
- from 1 pcs €3.00
- from 20 pcs €2.76
- from 30 pcs €2.70
Related products
Like TC2030-CTX-NL, but with a 0.05″ (1.27 mm) pitch 20-pin connector for I-Jet/ULINK Pro — not compatible with classic 20-pin 0.1″ connectors (e.g. standard J-Link).
- from 1 pcs €55.00
- from 20 pcs €50.60
- from 30 pcs €49.50
Programming cable for ARM Cortex targets with a 0.05″ (1.27 mm) pitch 20-pin connector, for IAR's I-Jet and Keil's ULINK Pro debuggers.
- from 1 pcs €55.00
- from 20 pcs €50.60
- from 30 pcs €49.50
