SpeedyProto Uno PCB · Prototyping Board for Arduino UNO
€2.50
- From 1 pcs: €2.50 / pc
- From 20 pcs: €2.30 / pc
- From 30 pcs: €2.25 / pc
Available, delivery time: 1-3 days
More than 5 in stock
Product information "SpeedyProto Uno PCB · Prototyping Board for Arduino UNO"
Short description
Prototyping board in the Arduino UNO footprint with a continuous ground plane. For compact, reliable prototype builds directly on the UNO.
Application
Stack this board on an Arduino UNO like a shield to extend it with your own circuitry — the header pins line up without bending, and a continuous ground plane makes a reliable ground connection possible at almost any point on the board, for analog and digital add-ons alike.
Technical data
- Form factor: fits the Arduino UNO, header pins pre-spaced for the Arduino footprint offset
- Board size: approx. 53×70mm
- Ground plane: continuous, can be contacted from any hole position
Variants
SpeedyProto Mega PCB (for Arduino Mega) · SpeedyProto Tiny PCB (small, platform-independent prototyping board, no Arduino footprint)
Accessories
10-pin Plug-of-Nails™ cable, no legs, with a 14-pin 1.27 mm (0.05″) ribbon connector in STDC14 format for STLINK-V3/STLINK-V3MINI.
- from 1 pcs €66.00
- from 20 pcs €60.72
- from 30 pcs €59.40
Like TC2050-IDC-NL-050, but with all 10 pins connected instead of leaving pins 5/9 open. No legs, for ULINK2 and similar debuggers with Samtec FTSH-105-01 style micro-headers on 1.27 mm (0.05″).
- from 1 pcs €65.00
- from 20 pcs €59.80
- from 30 pcs €58.50
Ten-pin debug and programming cable with spring pins that lands straight on the board — no connector on the target, just ten contact pads and six holes. The four legs hold it there while you work. At the other end, a standard 2.54 mm (0.1″) ribbon header that fits nearly every debugger.
- from 1 pcs €40.00
- from 20 pcs €36.80
- from 30 pcs €36.00
10-pin Plug-of-Nails™ cable (legged) to 1.27 mm (0.05″) pitch ribbon, for ULINK2 and similar debuggers with Samtec FTSH-105-01 style micro-headers. All 10 pins connected (unlike the standard TC2050-IDC-050, which leaves pins 5/9 open for ARM compatibility).
- from 1 pcs €65.00
- from 20 pcs €59.80
- from 30 pcs €58.50
Small prototyping board with a continuous ground plane, no Arduino footprint. For analog circuits on minimal board space.
- from 1 pcs €1.00
- from 20 pcs €0.92
- from 30 pcs €0.90
