SpeedyProto Mega PCB – Prototyping Board for Arduino Mega
€3.50
- From 1 pcs: €3.50 / pc
- From 20 pcs: €3.22 / pc
- From 30 pcs: €3.15 / pc
Available, delivery time: 1-3 days
More than 5 in stock
Product information "SpeedyProto Mega PCB – Prototyping Board for Arduino Mega"
Short description
Prototyping board in the Arduino Mega footprint with a continuous ground plane. For prototype builds that outgrow the UNO format.
Application
Stack this board on an Arduino Mega like a shield to extend it with your own circuitry — the header pins line up without bending, and a continuous ground plane makes a reliable ground connection possible at almost any point on the board, for analog and digital add-ons alike.
Technical data
- Form factor: fits the Arduino Mega, header pins pre-spaced for the Arduino footprint offset
- Board size: approx. 100×53mm
- Ground plane: continuous, can be contacted from any hole position
Variants
SpeedyProto Uno PCB (for Arduino UNO, approx. 53×70mm) · SpeedyProto Tiny PCB (small, platform-independent prototyping board, no Arduino footprint)
Accessories
10-pin Plug-of-Nails™ cable (legged) to 0.050″ pitch ribbon, for ULINK2 and similar debuggers with Samtec FTSH-105-01 style micro-headers. All 10 pins connected (unlike the standard TC2050-IDC-050, which leaves pins 5/9 open for ARM compatibility).
- from 1 pcs €65.00
- from 20 pcs €59.80
- from 30 pcs €58.50
10-wire programming cable with spring-pin Tag-Connector, direct contact with no mating connector needed on the target board. Terminates in a standard 0.1″ ribbon connector.
- from 1 pcs €45.00
- from 20 pcs €41.40
- from 30 pcs €40.50
10-pin Plug-of-Nails™ cable, no legs, with a 14-pin 0.05″ ribbon connector in STDC14 format for STLINK-V3/STLINK-V3MINI.
- from 1 pcs €66.00
- from 20 pcs €60.72
- from 30 pcs €59.40
Like TC2050-IDC-NL-050, but with all 10 pins connected instead of leaving pins 5/9 open. No legs, for ULINK2 and similar debuggers with Samtec FTSH-105-01 style micro-headers.
- from 1 pcs €65.00
- from 20 pcs €59.80
- from 30 pcs €58.50
Prototyping board in the Arduino UNO footprint with a continuous ground plane. For compact, reliable prototype builds directly on the UNO.
- from 1 pcs €2.50
- from 20 pcs €2.30
- from 30 pcs €2.25
10-wire programming cable with spring-pin Tag-Connector, no legs, direct contact with no mating connector needed. Terminates in a standard 0.1″ ribbon connector.
- from 1 pcs €45.00
- from 20 pcs €41.40
- from 30 pcs €40.50
Small prototyping board with a continuous ground plane, no Arduino footprint. For analog circuits on minimal board space.
- from 1 pcs €1.00
- from 20 pcs €0.92
- from 30 pcs €0.90
